- Six steps per box: lay out parts → sides to bottom → square and back on → face frame or stretchers → shelves and hardware → doors and hinge adjustment.
- Budget 15–25 minutes per cabinet once you are past the first two. The first box always takes longer — that is the one where you learn the joint.
- Squareness is the whole job. A box assembled out of square looks fine on the floor and will not accept its doors evenly on the wall. Check the diagonals before the back goes on, not after.
- Assemble on the floor, not on a bench. A flat floor is the flattest reference surface most kitchens have, and it stops a half-built box racking under its own weight.
- Assembly is not installation. Building the boxes is the easy half. Hanging them level on a wall that is not level is the half that decides how the kitchen looks.
- Find your exact model's instructions before you start. Lily Ann publishes per-SKU assembly pages — your cabinet's diagram beats any general guide, including this one.
Before You Start: Tools, Space and a Realistic Schedule
Most RTA (Ready-to-Assemble) cabinets need only a rubber mallet, a Phillips screwdriver or a drill on low torque, a carpenter's square and one or two clamps. No saw, no router, and on most designs no glue is strictly required — though glue at the corner joints is worth the two minutes.
The tool list is short because RTA cabinets are designed around it. The parts are pre-drilled, pre-cut and pre-finished; the assembly is a matter of bringing pre-made joints together in the right order and holding them square while you fix them. Where people get into trouble is almost never the tools.
What you actually need
- Rubber mallet — for seating cam and dowel joints without bruising a finished edge. A steel hammer will mark the finish; this is the one tool worth buying specifically.
- Drill or screwdriver — on the lowest clutch setting. Over-driving a screw into a pre-drilled hole strips it, and a stripped hole in a side panel is not easily fixed.
- Carpenter's square or tape measure — for checking diagonals. This is the single most important check in the whole process.
- Two clamps — to hold a corner square while you fix it. Optional on small boxes, genuinely useful on a 36-inch base.
- Wood glue — optional but recommended at the corner joints. It converts a mechanical joint into a permanent one and costs nothing in time.
- A clear stretch of floor — ideally carpet or a moving blanket, so finished faces are not resting on concrete.
How long it really takes
The honest answer is that the first cabinet takes two or three times as long as the fifth. A typical wall or base cabinet runs about 15–25 minutes once the sequence is familiar; the first one can easily take an hour while you work out how the joint goes together and where the back panel is supposed to sit.
For a full kitchen of, say, sixteen boxes, that means planning a full day for assembly alone — not an afternoon — and treating installation as a separate day. Corner cabinets, sink bases and tall pantry units take longer than a standard box, so front-load the simple wall cabinets to build up speed before you reach them.
Step 1: Lay Out and Count Every Part
Open the box, lay every part out face-up, and check it against the parts list before you assemble anything. A missing dowel found at step one is a phone call; the same dowel found at step four is a disassembled cabinet.
RTA cabinets ship flat with the parts stacked, usually with a hardware bag and a printed diagram. Take five minutes per cabinet to identify each panel — two sides, a bottom, a back, stretchers or a face frame, shelves, and the hardware bag — and confirm the count. Keep the diagram out; you will use it.
Two things worth doing at this stage: note which face of each panel is the finished side, because on some panels it is not obvious until the box is together and wrong; and check the panels for shipping damage now, while the cabinet is still a flat pack and easy to photograph and report.
Step 2: Join the Side Panels to the Bottom
Stand the two side panels up, slot the bottom panel between them, and seat the joints with the mallet. This forms a U — the structural core of the cabinet — and everything after this squares against it.
Most RTA designs use one of three joint types here: cam-and-dowel (a cam lock that turns to draw the joint tight), tongue-and-groove with screws, or a pre-drilled screw joint. Whichever yours uses, the principle is the same: bring the joint together fully before you tighten anything. A cam that is turned while the dowel is only half seated will either strip or hold the box permanently out of square.
If you are gluing, this is the joint to glue. A thin bead in the groove or on the dowel is enough — squeeze-out on a finished interior is harder to remove than it looks.
Step 3: Square the Box, Then Fit the Back
Measure both diagonals of the open box. When the two measurements match, the box is square. Fix the back panel at that point — the back is what locks squareness in permanently.
This is the step that decides whether the finished kitchen looks built or looks assembled, and it is the step most first-timers rush. A cabinet can be a quarter-inch out of square and sit perfectly happily on the floor. You will not see it. You will see it the moment two of those cabinets are side by side on a wall and their doors do not line up.
The diagonal check takes fifteen seconds: measure corner to opposite corner one way, then the other. Equal means square. If they differ, push the longer diagonal gently until they match, then fix the back immediately while it is held there. On most cabinets the back is a panel that slides into a groove or is nailed or screwed into a rebate; either way, once it is fixed, the box cannot rack.
Do not skip the back on a cabinet you plan to modify
If you intend to cut the back for plumbing on a sink base, cut it after assembly and squaring, not before. A back with a hole in it still braces the box; a back that was cut on the floor to a guessed position often does not fit at all.
Step 4: Fit the Face Frame or Stretchers
Framed cabinets get a face frame attached to the front edges; frameless cabinets get top and bottom stretchers instead. Both do the same job — holding the front of the box rigid and square.
On a framed cabinet the face frame usually arrives pre-assembled and attaches with dowels, screws or both. It should sit flush with the outer faces of the side panels; if it overhangs on one side, the box is out of square and step three needs revisiting before you fix the frame down.
On a frameless (European-style) box, top stretchers span between the side panels front to back. They look slight, and they carry more than they appear to — do not leave one out because the cabinet "seems fine without it".
Step 5: Shelves, Drawer Boxes and Hardware
Install shelf pins and shelves, then any drawer glides, then the drawer boxes. Doing hardware before the doors means you can test drawer travel while the box is still easy to move.
Shelf pins go into the pre-drilled line of holes in each side panel — count the holes rather than eyeballing the height, so the shelf sits level. Adjustable shelves are meant to be adjustable; leave them loose until the kitchen is loaded and you know what is going where.
Drawer glides are the part where a small error compounds. Under-mount soft-close glides in particular need to be mounted at matching depths on both sides, or the drawer front will sit skewed. Follow the pre-drilled positions rather than measuring your own, and test the drawer travel before moving on.
Step 6: Hang the Doors and Adjust the Hinges
Clip the hinges onto the mounting plates, then adjust. Modern concealed hinges have three independent adjustment screws — side-to-side, in-and-out (depth), and up-and-down — and every door will need at least one of them touched.
New assemblers often treat a door that sits slightly proud or slightly low as a mistake to be undone. It usually isn't. Six-way adjustable hinges exist precisely because doors need aligning after hanging, and the alignment is done on the wall, in the finished run, not on the floor.
The practical order: hang every door in the run first, then step back and adjust them together. Adjusting each door perfectly in isolation produces a run where every door is individually right and the gaps between them are all different — which is what the eye actually notices.
One thing to leave alone until installation: on cabinets that will sit next to each other, do not final-adjust the doors until the boxes are fixed to the wall. Hanging a box can shift it enough to undo the adjustment.
The Mistakes That Cost You a Cabinet
Four errors account for most damaged RTA cabinets: over-driving screws, hammering finished faces with a steel hammer, fixing the back before checking square, and assembling on an uneven surface.
- Over-driving screws. Pre-drilled holes in plywood have a finite amount of material. A drill on full torque strips them in a second, and a stripped hole in a side panel usually means a replacement panel.
- Steel hammer on a finished edge. Use the rubber mallet, or a block of scrap between hammer and panel. Finish damage on a visible edge cannot be sanded out without breaking through the finish.
- Back fixed before squaring. Covered above. It is the most consequential of the four because it is invisible until the doors go on.
- Assembling on an uneven floor. A garage floor with a drainage slope will build you a consistently non-square set of cabinets. Find a flat area, or work on a sheet of plywood.
And one that is not a mistake
Small gaps at the back of a face frame joint, or a hairline where two panels meet on an interior surface, are normal and invisible once installed. RTA tolerances are deliberately more forgiving than inset custom cabinetry — that forgiveness is part of what makes home assembly realistic in the first place.
Assembly Is Not Installation
Assembling the boxes and installing them are two different jobs with different skills. Assembly is repetitive and forgiving; installation depends on how out-of-level your walls and floors are, and that is where the real difficulty lives.
The sequence for installation: find the high point of the floor, strike a level line for the top of the base cabinets from there, locate and mark every stud, hang the wall cabinets first (working with an empty floor beneath you), then set the bases and shim them to the level line. Screw cabinets to each other before screwing them to the wall so the run stays as one aligned unit.
Shimming is not a sign that something went wrong. No wall is plumb and no floor is level; shims are how a square cabinet meets a non-square building. Expect to use them.
Find Your Exact Cabinet's Instructions
A general guide gets you through the sequence. Your specific model's diagram gets you through the joint. Lily Ann publishes per-SKU assembly instructions for its cabinets — find yours before you start.
This matters more than it sounds. A W3030 wall cabinet, a DB18-3 drawer base and a U189024 pantry go together differently, and the difference is in details a general article cannot cover: which panel the back slides into, how many stretchers there are, whether the drawer glides are pre-mounted. Lily Ann's assembly instructions library has a page per cabinet model and finish — for example, a Madison Linen W3030 has its own page separate from the Charleston Saddle DB18-3.
Have that page open on a phone or tablet while you work. It is the difference between assembling a cabinet and interpreting one.
If you are still choosing cabinets, the full ready-to-assemble range is at RTA kitchen cabinets, and every line uses the same construction — 1/2" plywood boxes, 5/8" dovetailed solid-wood drawers, full-extension soft-close glides and soft-close adjustable concealed hinges — so the assembly sequence above holds across finishes. For a broader look at whether RTA is the right buying route at all, see custom vs. builder-grade cabinets, and for where RTA sits among the three cabinet grades, stock vs. semi-custom vs. custom cabinets.
One piece the sequence above does not cover: the toe kick — the finished board closing the gap under the base run — goes on after everything is levelled and shimmed, which is why it is the last step of a kitchen install rather than part of any cabinet.
